L2
Web managed
16 10/100M RJ45 PoE ports
2 Gigabit combo ports
802.3af/at
PoE power budget 230W
max. 250m long distance transmission
VLAN
QoS
SNMP
IGMP snooping
STP ⠀⠀⠀⠀
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3z, IEEE 802.1Q, and IEEE802.3x Ethernet standards
16*10/100 Base-TX Ethernet ports, one 10/100/1000 Base-T Ethernet port and one 10/100/1000 Base-X SFP optical module port
Ports 1 – 16 are 10/100 Mbps downlink ports and comply with IEEE 802.3af and IEEE 802.3at.
The maximum of 30W port output PoE power and the maximum of 135W total output PoE power
Support four network modes: Priority, Standard, Isolate and Extend
4K MAC address and MAC address learning
7.2 Gbps backplane bandwidth
Store-and-Forward switching
All-mental construction
13 inch length and 1 U standard height size allow it to be mounted on subrack.
Power Input 100~240 V AC,50/60 H
