Flow Meter Avery Hardoll BM 250

flow-meter-avery-hardoll-bm-250/?preview=true”>Meter Series : BM 250

Size : 2 1/2 Inch
Repeatability Typically:± 0.02%
Max Working Pressure:10.5 Bar (150 Psi)
Hydraulic Test pressure :300 Psi
Max Working Temperature : – 28° to 100°C
Volume per-revolution:2.27 LITER/min
Flange Rating : Ductile Iron Steel ASA 150 FF

— Flowrate :25 ~ 250 Imp Gallon
— Flowrate :115 ~ 1140 l/m
— Flowrate : 7 ~ 68 m3/hr
Type : Direct Reading

Quick View

Flow Meter Avery Hardoll BM 950

Oil Flow Meter Avery Hardoll BM 950 Single Capsule

Meter Series : BM 950
Size : 3 inch
Repeatability Typically:± 0.02%
Max Working Pressure:10.5 Bar (150 Psi)
Hydraulic Test pressure :300 Psi
Max Working Temperature : – 28° to 100°C
Volume per-revolution:2.27 LITER/min
Flange Rating : Ductile Iron Steel ASA 150 FF

— Flowrate :30~300 Imp Gallon
— Flowrate :130 ~ 1370 l/m
— Flowrate :8 ~ 82 m3/hr
Type : Direct Reading

Quick View

Flow Meter LC Digital

SPESIFIKASI :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M5 (Capacity : 227 L/Min ( 60 GPM ))
M7 (Capacity : 380 L/Min ( 150 GPM )
M10 (Capacity : 550 L/Min ( 150 GPM )

Connection Size 3″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M15 Capacity : 760 L/Min ( 200 GPM )
M25 Capacity : 1135 L/Min ( 300 GPM )
M30 Capacity : 1325 L/Min ( 350 GPM )

Connection Size 4″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M-40 Capacity : 1700 L/Min ( 450 GPM )
M-60 Capacity : 2271 L/Min ( 600 GPM )
M-80 Capacity : 3000 L/Min ( 800 GPM )

Quick View

Flow Meter LC M-60-1

The LC Meter consists of a housing in which three rotors
turn in synchronized relationship within three cylindrical
bores with no metal-to-metal contact within the meter
element. Each rotor is supported on either end by a bearing plate
through which the rotor shafts protrude.
The bladed displacement rotors, alternately move through
the two half-cylinder bores of the meter element, while the
single blocking rotor rotates within its bore in such a way as
to produce a continuous capillary seal between the unmetered,
upstream product and the metered, downstream product.
At one end of each rotor shaft is a timing gear. The blocking rotor
gear, having twice the number of teeth of each of the
displacement rotor gears, rotates at half the RPM of the
displacement rotors.
Throughout the meter element the mating surfaces are either flat surfaces
or cylindrical faces and sections that are most accurately

• Capacity: 600 GPM (2,271 L/min.)
• Case made of aluminum with meter element components
of various materials as required for Classes 1, 2, 3, 14
and 15 construction.
• 4” square flanged spool and 4” companion flange
connection standard…NPT or BSPT threads. Choice of 4”
and 6” ANSI FF flanged connections and 4” and 6” Victaulic
spools. Also aluminum or steel welding flanges. 4” or 6”
ANSI RF, aluminum, forged flanged connections optional.

Quick View

Flow meter LC M15

Flow meter LC M15 Features and Benefits LC meters are exclusively engineered with no metal-to-metal contact within the measuring chamber, making use of a thin liquid capillary film between rotating and stationary components for hydraulic sealing. This unique design results in minimal wear, sustained accuracy, and low operating costs. When measuring the flow of a broad range of products, LC’s innovative design results in minimal resistance to flow and the ability to operate on pump pressure or gravity feed. That means efficient performance
and low pressure drop across the meter. LC’s combination of low pressure drop with minimum seal or slippage area offers better accuracy over a wide range of flow than other commercially produced PD meters.

Spesifikasi :

Flow Meter LC M15

Size : 3 inch
Accuracy : ± 0.2%
Repeatability : ≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature ) : – 40 to 160ºF (-40 to 71ºC
Meter Body : Aluminium , Cast iron , Steel , Stainless steel available
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Capacity : 757 L/Min ( 200 GPM )
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Other Types :

M5 (Capacity : 227 L/Min ( 60 GPM ))
M7 (Capacity : 380 L/Min ( 150 GPM )
M10 (Capacity : 550 L/Min ( 150 GPM )

Connection Size 3″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M15 Capacity : 760 L/Min ( 200 GPM )
M25 Capacity : 1135 L/Min ( 300 GPM )
M30 Capacity : 1325 L/Min ( 350 GPM )

Connection Size 4″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M-40 Capacity : 1700 L/Min ( 450 GPM )
M-60 Capacity : 2271 L/Min ( 600 GPM )
M-80 Capacity : 3000 L/Min ( 800 GPM )

Quick View

Flow Meter LC with Mechanical Counter and Printer

Features and Benefits LC meters are exclusively engineered with no metal-to-metal contact within the measuring chamber, making use of a thin liquid capillary film between rotating and stationary components for hydraulic sealing. This unique design results in minimal wear, sustained accuracy, and low operating costs. When measuring the flow of a broad range of products, LC’s innovative design results in minimal resistance to flow and the ability to operate on pump pressure or gravity feed. That means efficient performance
and low pressure drop across the meter. LC’s combination of low pressure drop with minimum seal or slippage area offers better accuracy over a wide range of flow than other commercially produced PD meters.

Types :

M5 (Capacity : 227 L/Min ( 60 GPM ))
M7 (Capacity : 380 L/Min ( 150 GPM )
M10 (Capacity : 550 L/Min ( 150 GPM )

Connection Size 3″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M15 Capacity : 760 L/Min ( 200 GPM )
M25 Capacity : 1135 L/Min ( 300 GPM )
M30 Capacity : 1325 L/Min ( 350 GPM )

Connection Size 4″ :

Accuracy : ± 0.2%
Repeatability :≤ 0.05 %
Standar Measurement : Unit Liter / US Gallon / imperial Gallon
Max Working Temperature :(-40° C to 71°C)
Meter Body : Aluminium , Cast iron , Steel
Connections : ANSI Flanged , NPT , BSPT , Slip Woled Available
Max.Pressure : 10.5Bar/150 PSI
Type : Direct Reading

Types :

M-40 Capacity : 1700 L/Min ( 450 GPM )
M-60 Capacity : 2271 L/Min ( 600 GPM )
M-80 Capacity : 3000 L/Min ( 800 GPM )

Quick View

FLow Meter Solar Gopas 9999 Series

FLow Meter Solar Gopas 9999 Series, Gopas Flow Meter dirancang untuk memenuhi tuntutan dari pelanggan yang perlu memonitor penggunaan bahan bakar secara akurat dan bisa diandalkan. Konstruksi yang kokoh, mudah dibaca, dan fleksibilitas instalasi bisa horizontal atau vertikal hanya dengan tiga fitur unggulan di flow meter ini. dan semua bisa di kalibrasi untuk meningkatkan akurasi.

Spesifikasi Gopas Flow Meter :

4 Digits Aluminum Mechanical Flowmeter
a. can connect with pumps for metering transfer
b. option for the unit on Liter and Gallon
c. no electricity need, usable on farm, mine and other place without electricity
d. 4 digits subtotals, 6 digits totals
Specification
4 Digits Aluminum Mechanical Flowmeter
Type : Series 9999 Meter
Size : 1 ½ Inch
Flow Rate : 30-120 L/min
Totalizer : 0-999999 Liter
Accuracy : ±1%
Body Materials : Aluminium
Max Pressure : 50 PSI/3 Bar
Applicable Media : kerosene, Diesel, Gasoline

Quick View

Frame Windsock ICN 45 cm Stainless Steel

Frame Windsock ICN 45 cm Stainless Steel, Frame ini digunakan untuk menempatkan Winsock agar mengikuti arah angin. pemasangan yang sangat mudah karena dilengkapi dengan drat.

Windsock adalah alat yang berfungsi sebagai penunjuk arah angin. Alat ini sangat berfungsi di dunia penerbangan. Setiap bandara wajib memiliki windsock sebagai
penunjang penentu arah angin

ICN Frame Windsock SS

frame ini dapat berputar 360 derajat, tahan karat, tahan lama

– Model Simpel
– Mudah dipasang dan digunakan
– Tersedia beberapa ukuran
– Pemasangan pada tiang cukup mudah hanya menggunakan drat.

Bahan :
– Stainless Steel 304
– Tahan Karat

Ukuran :
– Ø45 cm

Quick View

Nozzle Flomax FN-600

Nozzle Flomax FN-600 ukuran 1 1/2 Inch, Flomax diesel fuel nozzle with dog latch and sealing plug.
Dog latch mechanism with sealing plug. Designed for on-site refueling of construction, mining, forestry and agricultural equipment. Interchanges with Caterpillar and Wiggins

————————————————————————————————–

Integrated high flow swivel
Made of aluminum
Integrated sealing plug
Plug/bumper assembly gives complete nose seal
Tested to 180 gallons per minute

systems. 1-1/2″ female NPT. Integrated high flow swivel. Integrated sealing plug. Plug/bumper assembly gives complete nose seal. Tested to 180 gallons per minute. Investment cast aluminum housing.
Anodized aluminum non-wear parts. Heat treated stainless steel wear components. Delron bushings eliminate metal-to-metal wear.

Feature :

Integrated high flow swivel
Made of aluminum
Integrated sealing plug
Plug/bumper assembly gives complete nose seal
Tested to 180 gallons per minute
