Deskripsi [ ATV320U15M2C ] Schneider – ATV320 1,5KW 200V 1PH COMPACT
Selamat datang di toko DEWA ELEKTRICAL

Produk: ATV320 1,5KW 200V 1PH COMPACT
Kode Referensi: ATV320U15M2C

>>> Main <<<
Range Of Product: Altivar Machine ATV320
Product Or Component Type: Variable speed drive
Product Specific Application: Complex machines
Device Short Name: ATV320
Format Of The Control Block: Compact
Product Destination: Asynchronous motorsSynchronous motors
Emc Filter: Class C2 EMC filter integrated
Ip Degree Of Protection: IP20 conforming to EN/IEC 61800-5-1
Degree Of Protection: UL type 1 with UL type 1 conformity kit
Type Of Cooling: Fan
Network Number Of Phases: 3 phases
[Us] Rated Supply Voltage: 380…500 V (- 15…10 %)
Supply Frequency: 50…60 Hz (- 5…5 %)
Motor Power Kw: 0.37 kW for heavy duty
Motor Power Hp: 0.5 hp for heavy duty
Line Current: 1.8 A at 380 V for heavy duty1.4 A at 500 V for heavy duty
Prospective Line Isc: 5 kA
Apparent Power: 1.2 kVA at 500 V for heavy duty
Continuous Output Current: 1.5 A at 4 kHz for heavy duty
Maximum Transient Current: 2.3 A during 60 s for heavy duty
Asynchronous Motor Control Profile: Voltage/frequency ratio, 2 pointsVoltage/frequency ratio, 5 pointsFlux vector control without sensor, standardVoltage/frequency ratio – Energy Saving, quadratic U/fFlux vector control without sensor – Energy Saving
Synchronous Motor Control Profile: Vector control without sensor
Nominal Switching Frequency: 4 kHz
Switching Frequency: 4…16 kHz with current derating2…16 kHz adjustable
Safety Function: STO (safe torque off) SIL 3SS1 (safe stop 1)SMS (safe maximum speed)SLS (safe limited speed)GDL (guard door locking)
Communication Port Protocol: CANopenModbus
Optional Communication Modules: Communication module: CANopen daisy chain RJ45Communication module: CANope
